HPE-5S2-R40
5-Slot Backplane with 3 PCI Bus and 1 PCIe x4
User Manual Ver. 4.0
1.ATXPWR1: ATX Power Connector
１ １０
１１ ２０
2. PWR1: Voltage connector
PIN NO3 DESCRIPTION
1 +5V
2 GND
3 -12V
4 +12V
1 2 3 4
■ ● ● ●
Jan. 23, 2008
Pin Description Pin Description
1 +3.3Vdc 11 +3.3Vdc
2 +3.3Vdc 12 -12Vdc
3 GND 13 GND
4 +5Vdc 14 PS-ON#
5 GND 15 GND
6 +5Vdc 16 GND
7 GND 17 GND
8 PWRGD 18 NC
9 +5VSB 19 +5Vdc
10 +12Vdc 20 +5Vdc
