IEI Integration BP-4S-RS - Manual

1
BP-4S-RS-R40
4-Slot Backplane with 4 ISA Bus
User Manual Ver. 4.0
1. PW1 : AT Power Connector
2. CN1 : Voltage Connector
Nov. 16, 2007
Pin Description Pin Description
1 PWRGD 7 GND
2 +5V 8 GND
3 +12V 9 -5V
4 -12V 10 +5V
5 GND 11 +5V
6 GND 12 +5V
1 2 3 4 5 6 7 8 9 10 11 12
▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓
Pin Description
1 +5V
2 -5V
3 -12V
4 +12V
5 GND
1 2 3 4 5
▓ ▓ ▓ ▓ ▓
