4. CN12: Backplane to Mainboard Connector
1 2 3
5. CN8, CN11: Fan Connector
1 2 3
6. CN1, CN7: Voltage Connector
7. PW2: Power Connector
Pin Description
1 5VSB
2 PSON#
3 GND
Pin Description
1 NC
2 +12V
3 GND
Pin Description
1 +5V
2 -5V
3 -12V
4 +12V
5 GND
1 2 3 4 5
▓ ▓ ▓ ▓ ▓
Pin Description
1 +5V
2 +5V
3 +5V
4 GND
5 GND
6 GND
1 2 3 4 5 6
▓ ● ● ● ● ●
