7. PW3: Power Connector
8. PCI routing table:
PCI SLOT PCI3 PCI4
IDSEL AD31 AD28
REQ# REQ0# REQ3#
GNT# GNT0# GNT3#
INTA B A
INTB C B
INTC D C
INTD A D
PCI SLOT PCI5 PCI6 PCI7 PCI8
IDSEL 2_AD20 2_AD21 2_AD22 2_AD23
REQ# 2_REQ0# 2_REQ1# 2_REQ2# 2_REQ3
GNT# 2_GNT0# 2_GNT1# 2_GNT2# 2_GNT3
INTA C D A B
INTB D A B C
INTC A B C D
INTD B C D A
Pin Description Pin Description
1 PWR_GD 7 GND
2 +5V 8 GND
3 +12V 9 -5V
4 -12V 10 +5V
5 GND 11 +5V
6 GND 12 +5V
1 2 3 4 5 6 7 8 9 10 11 12
▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓ ▓
