5. RESET: External Reset Button Connector (System1)
RESET_A1: External Reset Button Connector (System2)
6. PWRGD: External Power Good Connector (System1)
PWRGD_A1: External Power Good Connector (System2)
7. SM-BUS: External System Management BUS Connector(System1)
SM-BUS_A1: External System Management BUS Connector(System2)
8. CN1: PCIE X16 SDVO Control Signal Pin(System1)
CN_A1: PCIE X16 SDVO Control Signal Pin(System2)
9. IOPWR: The I/O Power Connector indicators for controlling your CPU
board (System1)
IOPWR_A1: The I/O Power Connector indicators for controlling your
CPU board (System2)
PIN
DESCRIPTION
1 GND
2 SHB_RST#
2
●
1
■
PIN
DESCRIPTION
1 GND
2 PWRGD
2
●
1
■
PIN
DESCRIPTION
1 SMDAT
2 SMCLK
2
●
1
■
PIN
DESCRIPTION
1 EXP_EN
2 SDVO_CLK
3 SDVO_DAT
1 2 3
■ ● ●
PIN
DESCRIPTION PIN DESCRIPTION
1 GND
2 -12V
3 +12V
4 GND
5 IPMB_DA
6 5VSB
7 GND
8 GND
9 IPMB_CL
10 5VSB
11
+5V 12
PWRGD
13
SMDAT 14
SHB_RST#
15
5VSB 16
GND
17
SMCLK 18
PSON#
19
+3.3V 20
PWRBT#
19 17 15 13 11 9 7
5 3 1
● ● ● ● ● ● ● ● ● ■
● ● ● ● ● ● ● ● ● ●
20 18 16 14 12 10 8
6
4
2
