IEI Integration PE-4S v4.00 User Manual
Page 2

2
5. RESET: Reset Button Connector
6. PWRGD: External Power Good Connector
7. SM-BUS: External System Management BUS Connector
8. CN1: PCIE X16 SDVO Control Signal Pin
9. IOPWR : The I/O Power Connector indicators for controlling your
CPU board
PIN DESCRIPTION
PIN
DESCRIPTION
1 GND
2 -12V
3 +12V
4 GND
5 IPMB_DA
6 5VSB
7 GND
8 GND
9 IPMB_CL 10
5VSB
11 +5V
12 PWRGD
13 SMDAT
14 SHB_RST#
15 5VSB
16 GND
17 SMCLK
18 PSON#
19 +3.3V
20 PWRBT#
19 17
15
13
11
9
7 5
3
1
● ●
●
●
●
●
● ●
●
■
● ●
●
●
●
●
● ●
●
●
20 18
16
14
12
10
8 6
4
2
2
●
1
■
PIN
DESCRIPTION
1 GND
2 SHB_RST#
2
●
1
■
PIN
DESCRIPTION
1 GND
2 PWRGD
2
●
1
■
PIN
DESCRIPTION
1 SMDAT
2 SMCLK
1
2
3
■ ● ●
PIN
DESCRIPTION
1 EXP_EN
2 SDVO_CLK
3 SDVO_DAT
