5 RESET : Reset Button Connector
6 PWRGD : External Power Good Connector
7 SM-BUS : External System Management BUS Connector
8 CN1 : PCIE X16 SDVO Control Signal Pin
9 IOPWR : The I/O Power Connector indicators for controlling your
CPU board
PIN DESCRIPTION
PIN
DESCRIPTION
1 GND 2 -12V
3 +12V 4 GND
5 IPMB_DA 6 5VSB
7 GND 8 GND
9 IPMB_CL
10 5VSB
11 +5V 12
PWRGD
13 SMDAT 14
SHB_RST#
15 5VSB 16 GND
17 SMCLK 18 PSON#
19 +3.3V 20
PWRBT#
19 17 15 13
11
9
7
5
3
1
● ● ● ●
●
●
●
●
●
■
● ● ● ●
●
●
●
●
●
●
20 18 16 14
12
10
8
6
4
2
2
●
1
■
PIN
DESCRIPTION
1 GND
2 SHB_RST#
2
●
1
■
PIN
DESCRIPTION
1 GND
2 PWRGD
2
●
1
■
PIN
DESCRIPTION
1 SMDATA
2 SMBCLK
1
2
3
■ ● ●
PIN
DESCRIPTION
1 EXP_EN
2 SDVO_CLK
3 SDVO_DAT
