Warnings:
- Once the burner is light on, adjust the flame by turning the knob to obtain the desired intensity.
The setting must always be positioned between the maximum and minimum, and never
between the maximum setting and the off position.
- If the burner is difficult to light on, or if the flame is tall or irregular, turn off immediately
turning the knob to "off" position and call Assistance Service.
- If the particular nature of the local gas supply makes it difficult to ignite the burners with the knob
turned to the maximum setting, repeat the operation without a pan in position and with the knob
turned to the minimum setting and without pan stands.
- Warning: The ignition device must not be used for more than 15 seconds. If after this length of time the
burner does not light, or if it goes out again accidentally, wait 1 minute before trying to ignite it again
Grids
The panstand grids are designed to make the appliance easy and safe to use. Always check the
panstand grids are properly positioned before using the appliance. Furthermore, always check the
protective rubber feet are all present and correctly positioned.
Grid for small pots or pans (optional - Fig.1)
This is placed on top of the auxiliary burner grid (the smallest one) when pots or pans of reduced
diameter are used, to avoid unbalancing.
Choosing the right burner
The symbols stamped on the control panel (fig.2) near the knobs indicate which knob correspond
to which burner. To choose the most suitable burner, take into account the diameter of
the pan as well as the pan capacity (see table).
The diameter of the pan must be proportionate to the burner power in order to ensure high yield.
Pan diameter
Important!
- These instructions are intended for qualified technicians.
- The appliance must be installed correctly, in compliance with current laws.
- Before carrying out any operation on the appliance, it must be disconnected from the electric supply.
Fitting the appliance in the worktop
The cooktop may be fitted into any worktop, as long as it is heat resistant (minimum temperature of 90°C)
The dimensions of the hole to be made in the worktop and the minimum distances between rear
and side walls and those above the appliance are shown in figure 4.
Isolation below (fig.6):
- If the cooktop is installed without an oven below it, a separator panel must be placed between
the bottom of the cooktop and the housing below it, at a minimum distance of 10 mm.
INSTALLATION INSTRUCTIONS
R Rapid 200 mm 240 mm
SR Semi-rapid 160 mm 200 mm
A Auxiliary
60 mm (with
140 mm
reducer)
Ø minimum Ø maximum Burners
