6
MAXIMUM CAPACITY (DRY WEIGHT) 130 lbs. 60 kg
BASKET (TUMBLER) DIAMETER 44-1/2” 113 cm
BASKET (TUMBLER) DEPTH 42-1/2” 107.9 cm
BASKET (TUMBLER) MOTOR 3/4 HP 0.560 kw
BLOWER MOTOR 3 HP 2.238 kw
DOOR OPENING (DIAMETER) 31-3/8” 79.7 cm
BASKET (TUMBLER) VOLUME 38.2 cu. ft. 1.08 cu. m.
DRYERS PER 20'/40' CONTAINER 3/7
DRYERS PER 45'/48' TRUCK 9/9
VOLTAGE AVAILABLE 208-460v 3ø 3, 4w 50/60 Hz
HEAT INPUT 375,000 btu/hr 94,500 kcal/hr
APPROX. WEIGHT (UNCRATED) 1,500 lbs. 680.4 kg
APPROX. WEIGHT (CRATED) 1,725 lbs. 782.5 kg
AIRFLOW 2,150 cfm 60.88 cmm
INLET SIZE 1”
VOLTAGE AVAILABLE 208-600v 3ø 3, 4w 50/60 Hz
OVEN SIZE
kw btu/hr kcal/hr AIRFLOW
72 246,150 61,982 2,150 cfm 60.88 cmm
80 273,500 68,869 2,150 cfm 60.88 cmm
VOLTAGE AVAILABLE 208-460v 3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 1,650 lbs. 748.4 kg
APPROX. WEIGHT (CRATED) 1,875 lbs. 850.5 kg
HEAT INPUT 13 Bhp
STEAM CONSUMPTION 450 lbs./hr 202.2 kg/hr
AIRFLOW 2,150 cfm 60.88 cmm
SUPPLY CONNECTION 1-1/4”
RETURN CONNECTION 1-1/4”
COMPRESSED AIR CONNECTION 1/8” N.P.T.
COMPRESSED AIR VOLUME 0.75 cfh 0.02 cmh
Shaded areas are stated in metric equivalents
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
IMPORTANT: Steam dryers must be provided with a clean, dry, and regulated 80 PSI +/- 10 PSI
(5.51 bars +/- 0.68 bars) air supply.
NOTE: ADC reserves the right to make changes in specifications at anytime without notice or
obligation
Gas
Electric
Steam
