White’s Electronics Sierra Madre - Manual (Page 2)

2
Assembly
Assembly
ELBOW
CUP
STRAP ELBOW CUP
FOAM PADS
INSIDE ELBOW
CUP
CONTROL BOX
“S” ROD
LOOP CABLE
CAMLOCK
WASHERS
BETWEEN
EACH LOOP
EAR & CLEVIS
METER - INDICATES
TARGET INTENSITY
TRIGGER
(behind display)
BATTERY
COMPARTMENT
DOOR
BATTERY
COMPARTMENT
LATCHES
LOOP
CONNECTOR
HEADPHONE
JACK
CLEVIS
LOWER
ROD
BOTTOM OF
CONTROL BOX
Twist and insert each end of
handle (provided) through
top of shipping carton into
second flap.
(CARRY CARTON)
CABLE RETAINER
LOOP OR SEARCH
COIL
Remove decal paper from the two rub-
ber bumpers. Install on the bottom of the
control box, one in each of the front corners
(shown below by "X"). Press in place and
hold firmly for a few seconds then release.
CABLE
RETAINER
1. Center (Primary search)
2. Squeezed & held (Pinpoint)
3. Forward (Pinpoint lock)
"X" "X"
MODE
AUTO
GEB
TUNER
