Vortexx RK Series - Manual (Page 15)

Plunger Pumps
Operating Instructions and Parts Manual
RK Series Pumps
First Choice When Quality Matters
NORTH
AMERICA
Pos. Code Description Qty. Pos. Code Description Qty.
1380120 Shim
0.10 mm
1-3
1380130 Shim
0.20 mm
1-3
1380530 Shim
0.25 mm
1-3
40
1382810 Shim
0.05 mm
1-3
41 1380040 Open bearing support
(217 in/lbs)
1
42 740290 O-Ring
Ø 14x1.78
3
43 1980740 Plug
3/8” G
2
44 1260470 Bolt
M8x10
4
1380141 Rail
5/8”
2
Z-Bracket
1-3/4
Rail
1-3/4”
2
45
Z-Bracket Rail
2-5/8”
2
1980740 Plug
3/8” G
1
46
1981180 Plug
3/8” G NP F
1
47 180101 O-Ring
Ø 17.5x2
1
820361 Plug
1/2” G
1
48
960870 Plug
1/2” G NP F
1
1381070 Pump head
- NP Ø 18 F
1
1381071 Pump head
- Brass Ø 18
1
1380020 Pump head
- Brass Ø 20-22
1
49
1380680 Pump head
- NP Ø 20-22
1
50 820150 Head bolt
M8x70 (217 in/lbs)
8
77 840370 Bearing 1
1389270 Complete pump head
Ø 18
1
1389272 Complete pump head
Ø 18 H
1
1389271 Complete pump head
Ø 18 F
1
1389212 Complete pump head
Ø 20 H
1
78
1389220 Complete pump head
Ø 22 H
1
86 1260250 Oil sight glass 1
87 1260430 Snap ring 1
88 1780690 Contrast disc 1
89 1140450 O-Ring
Ø 20.24x2.62
1
AR64516 Oil 1
O
il
C
apaCity
- 15
Oz
1 960160 O-Ring
Ø 17.86x2.62
6
960090 Valve cap
- Brass (478 in/lbs)
6
960850 Valve cap
- SS (478 in/lbs) F
6
1380740 Valve cap
- NP (478 in/lbs)
6
960090T Valve cap
- 1/4” threaded - Brass (478 in/lbs)
1
2
960850T Valve cap
- 1/4” threaded - SS (478 in/lbs)
1
3 1389051 Complete valve 6
4 880830 O-Ring
Ø 15.54x2.62
6
880581 Plug
1/4” G - Brass
2
5
1380690 Plug
1/4” G NP F
2
6 820510 O-Ring
Ø 10.82x1.78
2
960110 Support ring
Ø 18 n
3
840300 Support ring
Ø 20³
3
11
840320 Support ring
Ø 22«
3
880320 High pressure packing
Ø 18 n
3
840290 High pressure packing
Ø 20³
3
12
840330 High pressure packing
Ø 22«
3
1380090 Piston guide
Ø 18 n
3
1380150 Piston guide
Ø 20
3
13
1380160 Piston guide
Ø 22«
3
14 961240 O-Ring
Ø 31.47x1.78
3
880330 Low pressure seal
Ø 18 n
3
840280 Low pressure seal
Ø 20³
3
15
840340 Low pressure seal
Ø 22«
3
16 1383130 Oil seal 3
17 850370 Bolt
M8x16 (217 in/lbs)
8
18 1380050 Closed bearing support 1
19 640030 O-Ring
Ø 59.99x2.62
2
20 2280240 Bearing 1
21 1382770 Pump housing 1
22 880130 Vented oil cap 1
23 962010 Nut
M8 (106 in/lbs)
3
24 962000 Washer
Ø 8.1
3
1380940 Ceramic piston
Ø 18 n
3
1380930 Ceramic piston
Ø 20³
3
25
1382360 Ceramic piston
Ø 22«
3
26 1380950 Spacer 3
27 600180 O-Ring
Ø 7.66x1.78
3
28 1380920 Guiding piston 3
29 1380060 Piston pin 3
1383020 Con rod
- Bronze > 3000 PSI
3
30
1383050 Con rod
- Aluminum < 3000 PSI
3
31 1080401 Back-up ring 3
32 1381850 Washer 8
34 1780510 O-Ring 1
35 1789010 Complete cover 1
36 1343510 Bolt
M6x14 (89 in/lbs)
6
2280070 Crankshaft
24mm «
1
37
2280060 Crankshaft
24mm n³
1
38 1380520 Key 1
39 180340 Oil seal 1
Legend
Ш
18
Ш
20
Ш
22
For n For ³ For «
RK15.15 RK18.20H RK21.20H
RK15.20H RK18.28H F
RK15.28HF
F Over 3600psi
