Standard timing table
If the selected timing is NO T included in table below, this LCD monitor will go into the sleep mode.
VESA MODES
Horizontal Vertical
Mode Resolution Total Nominal
Frequenc
y
+/-0.5KHz
Sync
Polarity
Nominal
Frequency
+/-1Hz
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
640*480@60Hz 800*525 31.469 N 59.940 N 25.175
640*480@72Hz 832*520 37.861 N 72.809 N 31.500
VGA
640*480@75Hz 840*500 37.500 N 75.000 N 31.500
800*600@56Hz
1024*625 35.156 P 56.250 P 36.000
800*600@60Hz 1056*628 37.879 P 60.317 P 40.000
800*600@72Hz 1040*666 48.077 P 72.188 P 50.000
SVGA
800*600@75Hz 1056*625 46.875 P 75.000 P 49.500
1024*768@60Hz 1344*806 48.363 N 60.004 N 65.000
1024*768@70Hz 1328*806 56.476 N 70.069 N 75.000
XGA
1024*768@75Hz 1312*800 60.023 P 75.029 P 78.750
1280*1024@60Hz 1688*1066 63.981 P 60.020 P 108.000 SXGA
1280*1024@75Hz 1688*1066 79.976 P 75.025 P 135.000
IBM MODES
EGA 640*350@70Hz 800*449 31.469 P 70.086 N 25.175
720x400@70Hz 900*449 31.469 N 70.087 P 28.322
MAC MODES
SVGA 832*624@75Hz 1152*667 49.728 N 74.551 N 57.284
XGA 1024*768@60Hz 1312*813 48.780 N 60.001 N 64.000
XGA 1024*768@75Hz 1328*804 60.241 N 74.927 N 80.000
