Operating Your TERK
HDTVa Antenna Pro
1. Rotate the antenna base so that the small end of the
UHF element faces the broadcast tower to seek the
best quality picture.
You can use the following Web tool to find where the
broadcast towers are located:
Use the web to find where the broadcast towers
are located:
1. Go to www. terk.com and click the “Antenna
Locator.”
2. Enter your home’s address and then “Submit.”
3. Click “View Street Level Map”
to see which direction you
should point your antenna
towards.
See Fig. 5.
2. Once you have positioned the
UHF elements to receive the
best UHF picture channels
14-69, then extend the two dipoles.
For best results on channels 2 through 6, extend the
dipoles to their full length and position them
horizontally.
For channels 7 through 13, shorten the dipole elements
and place at a "V" angle as required.
HD
TV
a
4
Fig. 5
