3
The steps listed below show you how to configure all the
hardware and software:
1. Use the DIP Switch to change the ID / Baud Rate /
Mode setting.
2. Please connect the devices as the example picture
shows below:
CMS Setup
For setup and operations on CMS, please refer to the
complete User Manual.
Alarm In
GND
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm Sensor Controller
Control Out
GND
NO 1
NC 2
NO 3
NO4
