Select Location
The proper location will ensure peak performance of your
appliance. Choose a location where the unit will be out of
direct sunlight and away from heat sources. Best
performance will be maintained when installed within the
following parameters:
A gap of 24in (606mm) is recommended between units for
moving the refrigerator. A clearance of 3in (76mm) is
required to the side of the unit that the hinges are located
on to allow for the door to open 90° degrees. Please see
diagram for recommendations for built in applications.
Cabinet Clearance
Adjacent cabinets and countertop can be installed on top,
back and sides of the unit as long as the grille and door
access remain unobstructed. Ventilation is required for the
bottom front section of the unit where the grille is located.
Keep this area open and clear of any obstructions.
Make certain that the leveling legs supplied with the wine
cooler are installed according to the instructions. Leveling
adjustments can be made by raising or lowering the glides
on the bottom of the unit.
Installing Your Refrigerator
All specifications and product design subject to change without notice.
Such revisions do not entitle the buyer to corresponding changes, improvements,
additions, replacements or compensation for previously purchased products.
4
Ideal Ambient Temperature Range
Built-in 65° – 80°F
Free-Standing 65° – 90°F.
wall structure
adjacent cabinet
left hand swing right hand swing
3“/76mm
24” 24”
DISCONNECT POWER SOURCE BEFORE
ADJUSTING LEVELING LEGS
