80 PLUS® C
ERTIFICATION
80 PLUS® certification is the most widely recognized
independent standard in power supply efficiency. An 80
PLUS® certified power supply uses less energy and
generates less heat to stay cooler, run quieter and last
longer. The EA-650 Platinum has been 80 PLUS®
PLATINUM certified to be at least 89% efficient at a wide
range of operating loads; this will lower your operating
costs and help protect the environment.
P OWER O UTPUT
To see the output capacity and regulation for each different voltage, see table 1.
T
ABLE
1
Output Voltage Load Max. Regulation Ripple & Noise
+3.3V 20A ±5% < 50 mV
+5V 18A ±5% < 50 mV
+12V1 30A ±5% < 120 mV
+12V2 30A ±5% < 120 mV
+12V3 30A ±5% < 120 mV
+12V4 30A ±5% < 120 mV
-12V 0.3A ±10% < 150 mV
+5VSB 3A ±5% < 50 mV
