Applica LME9000MW User Manual
Page 3
1
15
14
2
4
3
5
6
7
13
12
11
8
9
10
16
4
3
Product may vary slightly from what is illustrated.
1. ON/OFF button.
Important: When the On/Off button is in the Off position it only disables
the rake function.
2. Timer
3. Warranty board
† 4. Battery compartment cover (Part# LME9000MW-01) (batteries not included)
5. Blue LED ionizer light
6. Ionic air cleaner
7. Motor housing
† 8. Removable rake (Part# LME9000MW-02)
† 9. Litter tray (Part# LME9000MW-03)
10. Sensors (both sides)
† 11. Waste receptacle compartment cover with flaps (Part# LME9000MW-04)
12. Receptacle supports
Right (Part# LME9000MW-05) and Left (Part# LME9000W-06)
13. Top housing
14. Plug holes for Plug 2 (1 each side)
15. Cutout handle (1 each side)
16. Plug holes for Plug 1 (1 each side)
† Consumer replaceable/removable parts
† 1. Tent plugs type 1 and 2 (4) set (Part# LME9000MW-07)
† 2. Cleaning brush (Part# LME9000MW-08)
† 3. AC adapter (Part# LME9000MW-09)
† 4. LitterMaid
®
scoop and rake cleaner (Part# LME9000MW-10)
† 5. Paw cleaning ramp (Part# LME9000MW-11)
† 6. Carbon Filters (8 included) (Part# LMF200) (12 pk.)
† 7. Disposable waste receptacle (8 included)
(12 pk.) (Part# LMR200)
(18 pk.) (Part# LMR300)
† Consumer replaceable/removable parts
