9
3. Description of the controls
3.1 Front panel
All the dishwasher's controls and indicators are located on the front
panel. Programming and option selection are only possible with the door
closed.
1 ON/OFF BUTTON
2 SELECTION PROGRAM BUTTON
3 PROGRAM PHASE INDICATOR LIGHTS
4 START/PAUSE BUTTON
5 PROGRAM STARTED/STOP INDICATOR LIGHT (*)
6 PROGRAM DELAY BUTTON
7 PROGRAM DELAY LIGHT
8 "3/1" OPTION BUTTON
9 "3/1" OPTION LIGHT
10 ½ LOAD WASH BUTTON
11 ½ LOAD WASH LIGHT
12 3-FIGURE DISPLAY (remaining time, program delay, alarms)
13 NO SALT WARNING LIGHT
14 NO RINSE AID WARNING LIGHT
15 DOOR HANDLE
(*) flashes while the program is in progress, stops flashing and remains on at
the end of the program, or if the program is interrupted (intentionally or due
to a malfunction).
