7793C 6 rev. 04/13/11
PARTS LIST
MODEL 7793C
CAPACITY: 1/2 TON
TELESCOPIC TRANSMISSION JACK
* Only available in seal kit, RS7793SK.
** Only available in bolt kit: RS7793BK.
*** Only available in RS305004WK Wheel Kit ( hardware for 2 casters)
Complete replacement hydraulic unit assembly: RS7793CHU (incl. 2-1 to 6-11).
Only index numbers identified by Part Number are available separately.
Index No. Part No. Description Qty.
2-1 Guide Bolt 1
2-2 Screw M8x10 1
2-3 O-Ring 1
2-4* O-Ring 1
2-5 Piston Rod A 1
2- Nut 1
2-7 Retaining Ring 22 1
2-8 Ram Bearing 1
2-9 Piston Rod B 1
2-10 Oil Cylinder 1
2-11* Gasket 1
2-12* Filter 1
2-13 Ram Seat 1
2-14* O-Ring 2
2-15 Pump Seat 1
2-16 Pin 1
2-17 Steel Ball 7 mm 1
2-18 Spring 1
2-19 Screw 1
2-20 Screw M8x8 1
2-21 Steel Ball 6 mm 1
2-22 Lock Washer 10 4
2-23 Allen Screw M10x45 4
2-24* Gasket 1
2-25 Oil Container 1
2-26 Handle Sleeve 2
2-27 Handle 1
2-28 Lock Washer 8 1
2-29 Hex Nut M8 1
2-30 Hex Bolt M8x45 1
2-31* Gasket 1
2-32 RS7793VS Reservoir Vent Screw (incl. 2-31) 1
2-33* O-Ring 1
2-34* O-Ring 1
2-35* O-Ring 1
2-36* Piston Cap 1
3-1 Release Knob 1
3-2 Hex Nut M12 1
Index No. Part No. Description Qty.
3-3 RS7793BRR Oil Return Valve Rod (incl. 3-1, 3-2, 3-3) 1
3-4* Gasket 1
4-1 RS7793FPA Pedal A ( incl. 4-1 to 4-9) 1
4-2 Shaft 1
4-3 Shaft 1
4-4 Adapter Sleeve 1
4-5 Lock Washer 1
4-6 Retaining Ring 14 6
4-7 Shaft 2
4-8 Link Rod 1
4-9 Allen Screw M6x30 1
5-1 Pump Plunger 1
5-2* Retaining Ring 1
5-3* O-Ring 1
5-4 Spring 1
5-5* O-ring 1
5-6* RS7793PA Pump Cylinder Assembly
(incl. 5-1 to 5-7) 1
5-7 Washer 1
6-1 Locking Nut M6 1
6-2 Washer 6 1
6-3 O-Ring 1
6-4 Valve 1
6-5 Spring Sleeve 1
6-6 Spring 1
6-7 Valve Sleeve 1
6-8* O-Ring 1
6-9* Gasket 1
6-10 Steel Ball 8 mm 1
6-11 RS7793BRV Pedal B Release Assembly
(incl. 6-1 to 6-9, 6-11)
1
7-1 RS540062 Leg 2
7-2 RSSC301A 3" Swivel Caster 4
7-3*** Hex bolt M8x25 16
7-4*** Washer 8 16
7-5*** Nylon Lock Nut M8 16
7-6** Hex Bolt M12x25 4
7-7** Lock Washer 12 4
Not Shown RS7793CLK Product Label Kit 1
