Specifications

General Characteristics

Size

17.75" W x 3.5" H x 12"D

Front Panel

• Main Display 160x240 graphical LCD,

backlit

• Display indication for all 3 zones
• Power On/Off button
• Channel Up/Down buttons (buttons

repeat if held down)

• Category Left/Right buttons
• Select button
• Zone button
• Preset button
• 0–9 direct entry buttons
• Infrared receiver eye

Receiver Unit Specifications

RF/System

• Physical: Single SMA to Antenna
• Input Frequency: S band
• Input Level: – 65dBm to –20dBm
• Input Impedance: 50 ohms
• Demod / Descrambling: SIRIUS

Proprietary

Analog
Performance/Connectors

• Compression: ePAC
• Conversion: 24 bit D/A
• Frequency Response: 20 to 20kHz ±3dB
• Harmonic Distortion: < 0.02%
• Output Level: 2VRMS maximum

Rear Connectors

• RF Input: Female SMA
• Audio Line Out Connectors: 3 pairs RCA:

Left, Right

• Digital Audio: 3X S/PDIF TOSLink
• IR: Hard wired IR input via a 3.5mm tip

jack connector

• Data Control Port: DB9 RS232: data rate:

19,200 baud, no parity, 8 data bits, 1
stop bit, 3 wire (Rx,Tx & Gnd) interface

• AC input: 3 wire cord

General

• LNA Supply: 7.5 volts, 250mA
• Power Input: 85–140VAC, 50–60Hz
• Certifications: UL, FCC Part 15 Class B
• Operating Environment: 0–40C, 0-95%

Relative Humidity non-condensing

Antenna

• Input Frequency: Min: 2.32GHz,

Max: 2.33GHz

• LNA Noise: 0.7 dB at 25°C typical
• LNA Gain: 42dB typical
• Operating Temperature: – 40°C to +85°C
• VSWR, Antenna Module Output: 2:1 at

Zo = 50 ohms

• Power Requirements: 5.3– 8Vdc
• Cable Type: RG58U
• Output Connector Type: SMA female plug

Main Product System

The product as packaged for sale will
include the following:
• Antex branded SIRIUS Multizone

Receiver

• Remote Control
• Antenna
• 3 RCA stereo audio patch cables
• Owner’s Manual

Accessories

• Home Installation Kit: Includes detailed

installation instructions, a standard 35
foot RG58U cable and a mast. Mast
hardware required for home installation.

• Optional SMB Adapter: Residential

antenna systems available at retail
stores are terminated with SMB push-
on connectors that are compatible with
SIRIUS PnP home kits.A SMB adapter
may be purchased with the multizone
receiver if compatibility with retail resi-
dential antennas is desired.

• Mast: Needed to set the antenna away

from obstacles that may interfere with
the reception of the satellite signals.

• Standard Cable: 35 feet, RG58U, 50

ohms, terminated with male SMA con-
nectors.

• Extension Cable: Extension cables may

be required to accommodate certain
installation requirements.

• In-line Amplifier: Required to make up

for loss associated with extending the
length of the feed cable and other
components in the system.
