INSTALLATION – GETTING CONNECTED
Episode ® powered subwoofers are among the most flexible on the market today and can be configured for use in many different applications,
as shown in the figures below.
EPISODE ® POWERED SUBWOOFER INSTALLATION USING LOW-LEVEL INPUTS
5
Left &
Right
Preamp
Output
(Optional)
Left &Right
Preamp Output
(Optional)
High Level /
Speaker
Level
Output
Do Not Use
When Utilizing
“Low Level”
Inputs.
Loop to an
Optional
Second
Subwoofer
LFE Output
ES-SUB-10-200
& ES-SUB-12-300
ES-SUB-8-110
LFE Output
