ASKO Laundry Solutions - Manual (Page 17)

Drying Cabinet
DC7171 DC7181
Clothes Line Equivalent 52 1 /
2
' 52 1 /
2
'
Drying Time, Normal 150 min 150 min
Programs Normal, Low, Normal, Low,
Air Fluff Air Fluff
Timer Up to 4 hrs Up to 4 hrs
Element 1200 W 1200 W
CFM 26 26
Voltage 120V/60 Hz 120V/60 Hz
Bar for Hangers • •
Door Hanger • •
Glove Hanger • •
Colors White, Titanium White, Titanium
Shoe Rack (Accessory) Optional Optional
Height 67" to 69" 71 3 /
8
" to 73 3 /
8
"
Width 23 1 /
2
" 23 1 /
2
"
Depth 25 1 /
4
" 25 1 /
4
"
Depth with Door Open 46 1 /
4
" 46 1 /
4
"
Weight 132 lbs 143 lbs
FI Door Panels
Standard Panel
8080695 - 0 = White, - 86 = Black, - 91 = TouchProof™
Stainless Steel
Door Panel with T-Bar Handle (4” Toe Kick)
Height
30 1 /
8
"
Width 23 1 /
2
"
Thickness 5/8"*
Weight 19 lbs
8080696 - 0 = White, - 86 = Black, - 91 = TouchProof™
Stainless Steel
Door Panel with A-Bar Handle (4” Toe Kick)
Height
30 1 /
8
"
Width 23 1 /
2
"
Thickness 5/8"*
Weight 19 lbs
Full Panel
8081936 - 0 = White, - 86 = Black, - 91 = TouchProof™
Stainless Steel
Door Panel with T-Bar Handle (Full Door)
Height
32 9 /
16
"
Width 23 1 /
2
"
Thickness 5/8"*
Weight 18 lbs
*Custom panel should be a minimum of 3/4” thick
Ironing Board
8080704 - 0 = White (W6903)
8080705 - 0 = White, - 81 = Titanium (W6903FI, W6222)
Height
6"
Width 23 1 /
2
"
Depth 23 1 /
4
"
Depth at Max. Reach 59 1 /
2
"
Ironing Board Dimensions 36 1 /
2
" long X 12 5 /
8
" wide
Arm Insert Width (Optional) 16 3 /
4
" added to
width when installed
Weight 53 lbs
Arm Insert Weight 3 lbs
Double Shelf
8080443 - 0 = White, - 81 = Titanium (W6903)
8080407 - 0 = White, - 81 = Titanium (W6903FI, W6222)
Height
6"
Width 24 1 /
2
"
Depth 23 1 /
4
"
Depth at Max. Reach 47 3 /
4
"
Shelf Working Surface 25 1 /
2
" long X 21" wide
Basket Work Area 14" long X
19
1 /
4
" wide
Weight 58 lbs
Single Shelf
8079977 - 0 = White, - 81 = Titanium (W6903, W6903FI)
8061907 - 0 = White, - 26 = Black, - 81 = Titanium (W6222)
Height
2"
Width 23 1 /
2
"
Depth 22 1 /
4
"
Depth at Max. Reach 37 5 /
8
"
Shelf Working Surface 14 3 /
4
" long X 21 3 /
8
" wide
Weight 25 lbs
Before purchasing any appliance, read energy cost and efficiency information at your retailer.
For complete product specifications please refer to the ASKO Product & Design Guide or visit www.askousa.com.
HiddenHelpers ™
Laundry Basket
8081560 - 0 = White, - 81 = Titanium (Line Series)
8081558 - 0 = White, - 81 = Titanium, - 91 = Stainless Steel
(Circle, FI Series)
Height 6"
Width 23 1 /
2
"
Depth 23 1 /
4
"
Depth at Max. Reach 37 1 /
4
"
Basket Working Surface 17 1 /
2
" L x
19" W
Weight 40 lbs
Sorting Unit
8081299 - 81 = Titanium (FI)
8082751 - 91 Sorting Unit Door Stainless Steel
8082753 - 91 XXL Sorting Unit Door Stainless Steel
Height
27"- 28”
Width 23 5 /
8
"
Depth* 23 5 /
8
"
Depth at Max. Reach 45
Weight 90 lbs
XXL Steel Laundry Platform
8082771 - 0 = White, - BB = Blazin’ Black, - PP = Pure Platinum,
- RR = Ragin’ Red
Height 16"- 17"
Width 27"
Depth 28 1 /
2
"
Depth w/Drawer Open 44"
Weight 63 lbs
*Add 2” for Towel Bar Handle
