Technical Specifications
Model No. KVM-0811 KVM-1611
PC Port 8 16
Console Port 1 1
PC Port Connector
(All Female Type)
VGA HDDB 15pin ( shared with PS2 keyboard and Mouse )
Console Port
Connector
(All Female Type)
PS/2 Keyboard Mini Din 6 pin
PS/2 Mouse Mini Din 6 pin
VGA HDDB 15pin
Daisy Chain Port
Connector
(All Female Type)
PS/2 Keyboard mini Din 6 pin
PS/2 Mouse Mini Din 6 pin
VGA HDDB 15pin
PC selection On Screen Display Manual, Hot Key, Push Button
PC Port LED 8 16
Bank 7 segment LED 1
On Screen Display Yes
Scan Intervals 5~99 Sec.
Keyboard Emulation PS2
Mouse Emulation PS2
VGA Resolution 1920X1440
Bandwidth 200MHz
Daisy Chain MAX
Level
8 levels
MAX PC Connection 120 128
Housing Metal
Power Adapter DC 12V 1A or DC 9V 1A
Operation Temp. 0~50 C
Storage Temp. -20 ~ 60 C
Humidity 0~80%, Non-Condensing
Size 19” Rack Mount / 1RU 19” Rack Mount/ 1RU
Weight (kg) 2.2kg 3.5kg
Dimension (mm) 445(L) X 160(W) X 45(H) 445(L) X 160(W) X 45(H)
