10
4. Adjust rail and input bracket A to rear of the rail then adjust bracket A to fit your cabinet. Install
2~3 screws (don’t tight-up) upon the length you need. One is forbidden.
5. Repeat step 1 ~ 4 for the other side.
6. Repeat step 3 ~ 10 of install console to finish installation.
2.1.5 Replace bracket B and C step (For cabinet depth is 504 ~ 614 mm):
1. Remove seven rear screws.
2. Take two original brackets out.
3. Input bracket B to rear of the rail.
bracket A
original bracket
original bracket
bracket B
