LevelOne FEP-1601 - Manual (Page 3)

3
3. Packing Contents
Inside the package you shall find:
(1)
19” 16-Port FE PoE Switch
(2) Power Cord
(3) User Manual
Please check if the packing is damaged or any component is missing. If so, please contact your
distributor.
4. Technical Specifications
Standards
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3x Flow Control
IEEE 802.3af /midspan PoE compliant
Features
MAC Address: 2K
Buffer Memory: 512K bits
Transmission Method: Store and Forward
Filtering/Forwarding Rates
100Mbps port - 148,800pps
10Mbps port - 14,880pps
Transmission Media
10BaseT Cat. 3, 4, 5 UTP/STP
100BaseTX Cat. 5 UTP/STP
PoE on each Port 15.4W/30W
Output PoE Pin 4, 5, 7, 8
LED Indicators
Per Port: Link/Act with 10/100M, PoE ON/OFF
Per Unit: Power
Power Input 100-240VAC, 50~60Hz
Dimensions 440 (without holder) Ч 118 Ч 38 mm (L x W x H)
Weight 2.2 kg
Operating Temperature 0 to 50℃
Humidity 10 to 90% RH (non-condensing)
Certifications FCC Class A, CE
5. LED Indicators
On the front panel of 16-Port PoE Switch, there are 33 LED indicators as the following;
POWER : “ Green On ” indicates power is on and normal.
LINK : “ Green On ” indicates each Ethernet LAN port is in connection.
“ Fast Flashing ” indicates each Ethernet LAN data activities at 100M.
“
Slow Flashing
” indicates each Ethernet LAN data activities at 10M.
PoE : “ Green On ” indicates Power over Ethernet function is enabled for each port.
“OFF” indicates the PoE is disabled, and it becomes a regular LAN port.
