3
4. Technical Specifications
Standards
IEEE 802.3/u 10/100BaseT/TX
IEEE 802.3x Flow Control
Midspan PoE compliant
Features
MAC Address: 4K
Buffer Memory: 512KB
Transmission Method: Store and Forward
Filtering/Forwarding Rates
100Mbps port - 148,800pps
10Mbps port - 14,880pps
Transmission Media
10BaseT Cat. 3, 4, 5 UTP
100BaseTX Cat. 5 UTP
PoE on each Port 30W
Output PoE Pin 4, 5, 7, 8
LED Indicators Port 1~8: 10/100M, PoE ON/OFF, Power
Power Adaptor
Input: 100-240VAC, 50~60Hz
Output: 56VDC 1.6A (90W)
Dimensions 165 Ч 100 Ч 40 mm (L x W x H)
Weight 0.6 kg
Operating Temperature 0 to 50℃
Humidity 10 to 90% RH (non-condensing)
Certifications FCC Class A, CE
5. LED Indicators
On the front panel of 8-Port FE PoE Switch, there are 17 LED indicators as the following;
POWER:
“ Green On ” indicates power is on and normal.
Port 1~8 LAN:
“ Green On ” indicates each Ethernet LAN port is in connection.
PoE: “ Green On ” indicates Power over Ethernet function is enabled for each port.
“OFF” indicates the PoE is disabled, and it becomes a regular LAN port.
6. Dip Switch Settings vs Power over Ethernet
Note that the dip switches can be switched ON and OFF anytime. However, it is
suggested that the dip switches be set ready before the PoE port is connected for
power management.
The device will be re-started if the overall PoE power consumption is over the
power budget. Please make less PoE ports enabled when over the power
budget.
1 ~ 8 ports DIP ON
Per PoE Port 15.4/30 Watts Injected
Maximum PoE Power 85 Watts
