Chapter 1 Introduction

The Wi-Fi Combo Router is a high-performance tool that supports wireless networking at home,
work, or in a public place. The Wi-Fi Combo Router supports a USB 3G modem card, either
WCDMA or EVDO and even HSDPA as well, and supports wireless data transfers up to 150M bps,
and wired data transfers up to 100 Mbps. The WiFi Combo Router is compatible with industry
security features.

1.1 Package List

WBR-6804
Power Adapter
RJ-45 LAN Cable
Quick Installation Guide
CD Manual/QIG
Antenna

1.2 Hardware Installation

A. Hardware configuration

LED Indicators

Power LED

Antenna
Reset Button
Mobile LED
WAN LED
WiFi LED
LAN LED
WPS Button
