Atlantis Land A05-15AX-C03 - Manual (Page 21)

ENGLISH
A05-1XAX-C0X_MX02 14
3.8 Volume adjust
Adjust the volume by OSD menu and software of the PC.
4. Specification
Model A05-15AX-C03 A05-17AM-C04 A05-19AM-C05
Panel 15” 17” 19”
Resolution 1024 x 768 1280 x 1024 1280 x 1024
Active area 304.128 x 228.096 mm 337.920 x 270.336 mm 376.320 x 301.056 mm
Pixel pitch 0.297 mm 0.264 mm 0.294 mm
Contrast 450:1 500:1 600:1
Brightness 250 cd/m
2
300 cd/m
2
250 cd/m
2
Response time 25 ms 12 ms 12 ms
Display colors 16.7 M 16.7 M 16.7 M
Viewing angle H: -75°/+75°, V: -75°/+60° H: -75°/+75°, V: -75°/+60° H: -75°/+75°, V: -75°/+60°
H-Frequency 30~60 KHz 30~81 KHz 30~80 KHz
V-Frequency 55~75 Hz 55~75 Hz 55~75 Hz
Plug & Play Yes Yes Yes
Input signal Analog Analog Analog
Video Input connector 15 pins D-Sub 15 pins D-Sub 15 pins D-Sub
Audio input connector No 1 Stereo input 1 Stereo input
Built-in speakers No 2 x 2 W 2 x 2 W
Power input connector Power jack Power jack Power jack
