ATP/AST Series Product Specifications
1. Product Specifications
1-1. Product Applicable
§ This specification is applied to the analog resistive touchscreen: ATP/AST Series.
1-2. Structure
§ Dimensions, structure, and shape are referred on the drawing attached.
1-3. Environmental Specifications
Specification Value
Operating Temperature -20°C to 70°C (no condensation)
Operating Humidity
-20°C to 60°C Less than 90%RH (no condensation)
Exceeding 60°C 133.8g/m
3
(no condensation)
Storage Temperature -40°C to 80°C (no condensation)
Storage Humidity
-40°C to 60°C Less than 95%RH (no condensation)
Exceeding 60°C 142.9g/m
3
(no condensation)
Chemical Resistance
(top surface)
Toluene, Tricholoroethylene, Athetone, Alcohol,
Gasoline, Machine Oil, Ammonia, Glass Cleaner,
Mayonnaise, Ketchup, Wine, Salad Oil, Vinegar, Lipstick, etc.
1-4. Mechanical Characteristics
Specification Value
Activation Force 0.05N to 0.8N
Operating Life
Input (finger) 10,000,000 hits
Character Input (pen) 100,000 characters
Light Transmittance Over 80% (typical value at full wavelength)
Surface Hardness Over 2H (by JIS pencil hardness)
1-5. Electrical Characteristics
Specification Value
Maximum Voltage DC6V
Maximum Current
Top Electrode 100mA
Bottom Electrode 100mA
Between the Top and Bottom 0.5mA
Linearity Under

2

Under

1% (typical value))
Terminal Resistance
Top Electrode Less than 1k

Bottom Electrode Less than 1k

Insulation Resistance
Neighboring Terminals Over 20M

at 25V
Active Area Electrodes Over 20M

at 25V
Chattering Less than 10msec at ON/OFF.
