ION Audio Archive LP User Manual
Page 27
27
Specifications
Power: 12V DC, 1A, center pin-positive, tip-negative
Dimensions: 13.75” x 16” x 3.46"; 360 mm x 406 mm x 88 mm
Weight: 5.9 lbs; 2.68 kg
Cartridge Type: Ceramic cartridge
Stylus Tip: Diamond tip
Track Force: 5 grams nominal (4-6 grams)
Output Voltage: ( at 1 kHz=3.54 cm/sec) 200-300 mV
Channel Balance: ( at 1 kHz) <=3dB
Channel Separation: ( at 1 kHz) >=15dB
Frequency Response: 80-10,000Hz (+-7dB)
Stylus: iCT09RS (diamond-tipped) included, also available at ionaudio.com/ict09rs
78 RPM stylus sold separately at ionaudio.com/ict06rs
Trademarks and Licenses
iTunes is a trademark of Apple, Inc., registered in the U.S.A. and other countries.
Phillips is a registered trademark of the Phillips Screw Company in the United States and other
countries.
All other product or company names are trademarks or registered trademarks of their respective
owners.
