PUBLIC ADDRESS AMPLIFIER
12 PA-2000A/4000A/6000A
Specifications Specifications
PA-2000A PA-4000A PA-6000A
Rated Output (RMS) 60W 120W 240W
Frequency CH 1~CH 6 120Hz-10kHz
Response Telephone In 330Hz-3.3kHz
Link In 80Hz-12kHz
Amp In 60Hz-15kHz
T.H.D CH 1~CH 6, Phono Less than 1%
Telephone In, Link In Less than 0.5%
Amp In Less than 0.05% Less than 0.5%
S/N CH 1~CH 6 more than 50dB
Phono more than 55dB
(CD for USA/CANADA) (more than 70dB)
Telephone In, Link In more than 65dB
Amp In more than 95dB
Graphic Equalizer
(100Hz,330Hz, 1kHz, 3.3kHz, 10kHz)
±12dB
Input Sensitivity CH 1~CH 6 -70~-22dB/600 Ω -70~-20dB/600 Ω
/Impedance Phono -54dB/22k Ω
(CD for USA/CANADA) (-6dB/20k Ω)
Link In -20dB/15k Ω
Telephone In EC & Associated, JAPAN : -2dB(0.775V)/600 Ω,
USA/CANADA & Associated : -10dB(0.3V)/600 Ω
Amp In 0dB/47k Ω 0dB/4.7k Ω
Speaker Output EC & Associated, 4 Ω/15.5V , 4 Ω/22V 4 Ω/30V
/Impedance JAPAN 8 Ω/22V 8 Ω/31V 8 Ω/43V
83 Ω/70V 42 Ω/70V 21 Ω/70V
165 Ω/100V 83 Ω/100V 41 Ω/100V
USA/CANADA & 4 Ω/15.5V 4 Ω/22V 4 Ω/30V
Associated 8 Ω/22V 8 Ω/31V 8 Ω/43V
10.4 Ω/25V , 5.2 Ω/25V -
83 Ω/70V 42 Ω/70V 21 Ω/70V ,
Preamp Out/Impedance 0dB/600 Ω
Link Out/Impedance -6dB/600 Ω
Operating Temperature -10˚C ~ +40˚C
Power Source 100–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 95W 120W 180W
Weight 10kg/22lb 12kg/26lb 13.5kg/29.76lb
Dimensions 420(W)x100(H)x320(D)mm 420(W)x133(H)x320(D)mm
16.5(W)x3.9(H)x12.5(D)in 16.5(W)x5.2(H)x12.5(D)in
* Specifications and design subject to change without notice.
