Sample: PROTOCOL ID Setting
BAUD RATE / OUTPUT MODE Setting
XXXX
Baud Rate 1 2 3 4 Remarks
Baud Rate 40K UP UP
UP UP 1080p60
UP DOWN 1080p50
DOWN UP 720p60
DOWN DOWN 720p50
Baud Rate 9600 DOWN DOWN
* Baud Rate / Output Mode Setting Condition
1) Switch No. 1 Baud Rate Control
2) Switch No. 2 Output Bypass Mode Control
KEYBOARD CONTROLLER
ID : 0001
11 2 3 4
ID : 0003
ID : 0013
ID : 0016
ID : 0002
.
.
.
.
11 2 3 4
11 2 3 4
