6: A LLOCATION N UMBERS
« FC4A M ICRO S MART U SER ’ S M ANUAL » 6-15
Special Data Registers for High-speed Counters
Special Data Register for Pulse Outputs (upgraded CPU modules only)
Special Data Registers for Analog Potentiometers
Special Data Register for HMI Module
Special Data Registers for Data Link Master/Slave Stations
Allocation
Number
Description Updated See Page
D8045 High-speed Counter 1 (I0-I2) Current Value Ever y scan 5-7, 5-8
D8046
High-speed Counter 1 (I0-I2) Reset Value (two-phase)
High-speed Counter 1 (I0-I2) Preset Value (single-phase)
5-7, 5-8
D8047 High-speed Counter 2 (I3) Current Value Ever y scan 5-8
D8048 High-speed Counter 2 (I3) Preset Value 5-8
D8049 High-speed Counter 3 (I4) Current Value Ever y scan 5-8
D8050 High-speed Counter 3 (I4) Preset Value 5-8
D8051 High-speed Counter 4 (I5-I7) Current Value Ever y scan 5-8
D8052
High-speed Counter 4 (I5-I7) Reset Value (two-phase)
High-speed Counter 4 (I5-I7) Preset Value (single-phase)
5-8
D8053-D8054 — Reser ved — — —
D8055 Current Pulse Frequency of PULS1 or RAMP (Q0) Ever y scan 20-4, 20-17
D8056 Current Pulse Frequency of PULS2 or RAMP (Q1) Ever y scan 20-4, 20-17
D8057 Analog Potentiometer 1 Value (All CPU modules) Ever y scan 5-30
D8058
Analog Potentiometer 2 Value (All-in-one 24-I/O type CPU)
Analog Voltage Input (Slim type CPU modules)
Ever y scan 5-30, 5-31
D8059-D8067 — Reser ved — — —
D8068 HMI Module Initial Screen Selection 5-34
D8069
Slave Station 1 Communication Error (at Master Station)
Slave Station Communication Error (at Slave Station)
When error occurred 25-4
D8070 Slave Station 2 Communication Error (at Master Station) When error occurred 25-4
D8071 Slave Station 3 Communication Error (at Master Station) When error occurred 25-4
D8072 Slave Station 4 Communication Error (at Master Station) When error occurred 25-4
D8073 Slave Station 5 Communication Error (at Master Station) When error occurred 25-4
D8074 Slave Station 6 Communication Error (at Master Station) When error occurred 25-4
D8075 Slave Station 7 Communication Error (at Master Station) When error occurred 25-4
D8076 Slave Station 8 Communication Error (at Master Station) When error occurred 25-4
D8077 Slave Station 9 Communication Error (at Master Station) When error occurred 25-4
D8078 Slave Station 10 Communication Error (at Master Station) When error occurred 25-4
D8079 Slave Station 11 Communication Error (at Master Station) When error occurred 25-4
D8080 Slave Station 12 Communication Error (at Master Station) When error occurred 25-4
D8081 Slave Station 13 Communication Error (at Master Station) When error occurred 25-4
D8082 Slave Station 14 Communication Error (at Master Station) When error occurred 25-4
D8083 Slave Station 15 Communication Error (at Master Station) When error occurred 25-4
D8084 Slave Station 16 Communication Error (at Master Station) When error occurred 25-4
