Level control (7)
This control is used to set the bass volume according to your preferences. Proceed as follows:
1. Set the bass control of your amplifier into its centre (linear) position.
2.
Important: Set the level control to its left stop (lowest volume).
3. Now, play back some music and set the volume control of the amplifier to the desired level.
4. Set the subwoofer level control to the desired bass level.
Warning: when connecting to an AV receiver‘s subwoofer output, the subwoofer level should be set to
0 dB in the receiver‘s set-up.
Cross-over frequency control (8)
Used to set the upper limit of the subwoofer operating range. The cross-over frequency should be set to
approxi-mately 100 to 150 Hz when the system is used in combination with shelf loudspeakers and to
50 to 100 Hz with stand loudspeakers.
Phase control (9)
In normal use the phase control should be set to 0°. However, in rare cases it may be advantageous to
vary the phase to between 0° and 360° (e.g. if the subwoofer is far away from the front satellites or in the
event of unfa-vourable acoustics in the room). Generally speaking: the setting where the lower base tone
area has a more natu-ral sound is the correct one.
MAINTENANCE
The lacquered surface is best cleaned with a mild household cleaner. On no account use furniture polish
or similar products on these surfaces. Please also do not use a microfiber cloth as this may damage the
surface.
SPECIFICATIONS
Configuration: Powered compact subwoofer
Fitted with: 20 cm woofer, 2 x 20 cm bass radiators
Output power RMS/Max.: 325 / 650 watts
Frequency range: 22 – 200 Hz
Cross-over frequency: 50 – 200 Hz, adjustable
Dimensions (WxHxD): 238 x 245 x 270 mm
Accessories: mains cable
SUBJECT TO TECHNICAL CHANGE.
