Page 8

User Interface Back

Most of the inputs and outputs on the

Echobode

backside are straight forward and

self-explanatory. The main exception is the

FREQUENCY SHIFTER NOTE

input. When

you connect the

NOTE

input,

Echobode

will enter a CV pitch following mode where the

frequency shift will follow the frequency of the CV note value you send to

Echobode

With this feature you can do harmonic shifting on monophonic sounds

("monophonic"

as in "non-polyphonic")

. If you do not have a CV source for your notes you can use the

built-in RPG-8 arpeggiator to convert notes to CV. The "SC Stroem Picher" combinator
is an example of such a patch.

Also notice that the separate

SIDEBAND

outputs do not feature

ANTI REFLECTION

(see above)

as this takes place after the

SIDEBAND

mix.
