Product exterior guide
Installation steps
1. Fan power switch
2. Power indicator light
3. Power cord connector
4. USB connector (Type B)
5. Ethernet connector (RJ-45)
1. Remove the NB02 from the packaging and place it on a flat surface of your choice
2. Please refer to the diagram and connect to all cables you wish to utilize
3. Connect the power adapter to an available power socket
4. Connect the included USB cable from the NB02 to your notebook computer
6. USB connector (Type A)
7. Microphone connector
8. Sound input connector
9. sound output connector
This is a multifunctional product so please familiarize with the content of this manual before usage.
If you have questions or comments at any time during the use of this product, please feel free to
contact us at : [email protected]
1 3 2 4 5 7 8 9 6
