7
Specifications
Features
• PIR motion detection coverage: up to 8m (26 ft)/40 degree horizontal;
6m (20ft)/75 degree horizontal
• Pet immunity weight: 5 Kg (11 lbs) to reduce false alarm
• Energy efficient with solar panel and backup batteries
(3xAA, not included)
• Ultra alarm sound 130dB for average home coverage
• Delay time to exit is 30 seconds and 5 seconds entry delay
• Programmable 4 digits security code via front four keys
• Battery low light indicator
• Low power consumption design with stand by current 20
μA
• Minimum lighting level for solar panel: 100 Lux
• Dimensions: 70 (W) x 116 (H) x 33mm (D) (2.75” x 45.67” x 1.30”)
PIR Range
Detecting Angle
Operating power
Power Consumption
Solar Lighting
Alarm Sound
Maximum Alarm Time
Pet Immunity
Security
Dimensions 8m/26ft
40° horizontal, 75° vertical
3 x AA (1.5v) Alkaline Batteries
20uA
100 Lux (minimum)
130dB
30 Seconds
11 lbs.
4 digit programmable code
70mm x 116mm x 33mm (WxHxD)
