Rivers Edge RE764 Perimeter Pod Curtain - Manual (Page 4)

TREESTANDS
Perimeter ™ Pod Curtain Kit (RE764)
Page 4
HuntRiversEdge.com
HuntRiversEdge.com
800-450-EDGE (3343)
POD PARTS
5
5
4
2
7
4
1
9
7
2
3
5
6
1
4
8
KEY # PART # DESCRIPTION QTY.
1 8909B BOLT 1/4-20 X 1-1/4 HHCS GR5 BLK 8
2 48153B BOLT 1/4-20 X 2 HHCS GR5 BLK 8
3 48240B BOLT 1/4-20 X 1-1/2 HH GR5 BLK 4
4 48261B WASHeR, BLK 1/4 12
5 48752B NUT, fLANGeD TOP LOCK, 1/4-20 20
6 AL7 fOOT PLATfORM, SIDe SUPPORT 4
7 TP161 RAIL, POD CURTAIN 2
8 TP162 UPRIGHT RAIL, SHOOTING 33-1/4" 4
9 TWR26 TUBe, RAIL SPANNeR 2
LADDER PARTS LIST
5
5
4
2
7
4
1
9
7
2
3
5
6
1
4
8
