KISAE SW 1220 Power Inverter 1000/2000 - Manual (Page 11)

Page 11
6. SPECIFICATIONS
Note: Specifications are subject to change without notices.
Specification
Modified Sinewave Series True Sinewave Series
MW 1210 MW 1215 SW 1210 SW 1220
Inverter
AC Output Power 1000W 1500W 1000W 2000W
AC Output Current 8.3A 12.5A 8.3A 16.6A
AC Surge Power (Peak) 2000W 3000W 2000W 4000W
AC Output Voltage 120 VAC / 60 Hz
AC Output Waveform Modified Sinewave True Sinewave
Nominal DC Input Voltage 12.5 VDC
No Load battery draw < 0.6 ADC < 1.2 ADC
DC Input Voltage operating range 10.5 – 15.5 VDC
Under Voltage Alarm 11.2 VDC
Under Voltage Shutdown 10.5 VDC
Under Voltage Recovery 11.8 VDC
Over Voltage Shutdown 15.5 VDC
USB 5V, 750 mA
Safety and Environmental
Conformance Conforms to UL 458
Certified to CSA C22.2 no. 107.1
Agency Markings cETLus
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Relative Humidity 5-90% noncondensing
Operating Altitude Up to 9,843ft (3000 meters) above sea level
Weights and Dimensions
5.3 lbs
(2.4 kg)
6.9 lbs
(3.1 kg)
6.0 lbs
(2.7 kg)
11.5 lbs
(5.2 kg)
Weights MW 1210: 5.3 lbs (2.4 kg)
MW 1215: 6.9 lbs (3.1 kg)
SW 1210: 6.0 lbs (2.7 kg)
SW 1220: 11.5 lbs (5.2 kg)
Dimensions MW 1210: 12.3 x 6.9 x 3.4” ( 31.2 x 17.5 x 8.7 cm)
MW 1215: 15.0 x 6.9 x 3.4” ( 38.2 x 17.5 x 8.7 cm)
SW 1210: 12.6 x 6.9 x 3.4” ( 32.1 x 17.5 x 8.7 cm)
SW 1220: 16.3 x 9.1 x 4.3” ( 41.4 x 23.0 x 11 cm)
