Keter Malaga 6 User Manual
Page 5
3
s18b (X3)
s18b (X3)
4
Use the positioning
template to place the
brackets. fold the
positioning guide wings.
Use a pencil to mark
through the
template the screw
position
Remove the template and
insert the
ds15 screw which goes
through the
post into the metal base
Attach the positioning template to
the post as shown. Place the bracket
within the positioning template hole
Screw 6 screws through the
brackets as shown
BRACKETS ASSEMBLY
1
4
2
5
3
ds15
Self-drilling
screw.
5
POSITIONING THE SECOND POST BASE
This side up
Rail must be leveled
A
EN
UP
DOWN
