Gc25高轮底盘及扶手表 – Havener 24SP with Horizontal Shaft Engine User Manual
Page 9
Item NO.
Part Number
Description
Qty
1
424B-025
Plow handle
1
2
400-034
Handle grip
2
3
400-028
Bail weldment
1
4
400-001
Grip
2
5
424B-026
Clutch guardⅡ
1
6
424B-027
Clutch
1
7
424B-028
Clutch guardⅠ
1
8
424B-029
connector panel
1
9
424B-030
Nylon Nut5/16
1
10
424B-031
Engine
1
11
424B-032
Hexagon Bolt M6x12 GB5789
7
12
424B-033
Engine washer
1
13
424B-034
Belt Guard
1
14
200-030
Nylon Nut M8 GB889-86
16
15
200-085
Hexagon Bolt M8X40 GB5782
4
16
424B-035
Eng. mount
1
17
200-178
Hexagon Bolt M8X16 GB5783
8
18
424B-013
CrossarmⅡ
1
19
400-025
Back wheel axel
2
20
400-020
Back wheel washer
4
21
400-026
Back wheel
2
22
200-097
Nut Flange M14 GB6187-86
2
23
200-172
Nylon Nut M14 GB889-86
2
24
424B-037
Belt Guard
1
25
200-006
Nylon Nut M10 GB889-86
1
26
422B-006
Rear deflector
1
27
200-095
Push rivet
4
28
424B-038
Engine Belaying Cleat
1
29
424B-039
Pull plate bracket
1
30
424B-040
Handrail connecting plate
2
31
200-119
Hexagon Bolt M8X25 GB5783
4
32
424B-041
Bolt M5x40 GB818-85
2
33
424B-042
Clutch controller support
1
34
200-013
Nylon Nut M5 GB889-86
2
35
424B-045
Clutch switch
1
36
424B-046
Clutch control handle
1
37
424B-043
Left Bail weldment
1
38
424B-044
Engine Belt
1
39
900-196
Rod End RH8
2
40
200-074
Hexagon Nut M8
2
41
424B-047
Travel control lever
1
