Havener Belt-Drive Mowers 32, 36, 48 & 52 User Manual
Page 35
12
32”, 36”, 48” & 52” Transmission Drive Assembly
Item No.
Part Number
Description
Qty
1
100-045
Flat Grip
1
2
100-046
Transmission Shift Lever Upper
1
3
100-047
Output Pulley
2
4
200-034
Nut 3/8-24
1
5
200-035
Screws M8*10 GB71-85
2
6*
N/A
Peerless Part
1
7
200-011
Bolt M6*16GB/T794-93
4
8
100-049
Flange Bearing
2
9
100-050
Traction Belt
2
10
200-036
Hexagon Bolt M6*20 GB5783-86
5
11
100-051
Belt Guide II
2
12
200-009
Nylon Nut M6 GB889-86
10
13
200-047
Snap Ring 16 GB894.1-86
2
14
100-052
Woodruff Key
2
15
100-053
Output Shaft
2
16
100-054
Coupling
2
17
200-026
Grease Fitting M6 GB1152-89
2
18
100-055
Neutral Switch Transmission
1
20
200-037
Hexagon Bolt 5/16-18
4
21
200-024
Lock Washer 8 GB93-87
4
22
100-057
Traction Spring
2
23
100-058
Idler Pulley II
2
24
200-032
Hexagon Bolt M10*50 GB5782-86
2
25
200-038
Hexagon Bolt M10*60 GB5782-86
2
26
200-010
Plain washer 10 GB95-85
2
28
200-016
Nut Flange M10 GB6187-86
2
29
100-059
Transmission Shift Lever Lower
1
30
200-006
Nylon Nut M10 GB889-86
2
31
200-031
Lock washer 10 GB93-87
1
32
200-039
Nylon Nut M4 GB889-86
2
33
200-040
Plain Washer 4 GB95-85
2
34
200-041
Bolt M4*30 GB818-85
2
35
100-060
Switch
1
37
100-061
Compression Spring
1
38
200-042
Plain Washer 6 GB95-85
1
39
200-043
Plain Washer 6 GB5287-86
1
41
200-044
Hexagon Bolt M6*40 GB5782-86
1
