1.2 Specifications
The following specifications are based on a one-year calibration cycle, an operating temperature of 18 to
28ºC (64 to 82ºF) and a relative humidity not exceeding 80%.
Table 1-1 List of Specifications
TUNER POWER METER SPECIFICATIONS
Power Range 10 pW to 10 kW (detector dependent)
Power Scales
(photodetector)
Autoscale
Power Scales
(thermal head)
25 scales: 10nW, 30nW, 100nW, 300nW, 1uW, 3uW, 10uW, 30uW, 100uW,
300uW, 1mW, 3mW, 10mW, 30mW, 100mW, 300mW, 1W, 3W, 10W, 30W,
100W, 300W, 1kW, 3kW, 10kW
Compatible detector
heads XLP12, all UP Series, PS 1.5k, PS 3k, PS 6k, all HP Series and all PH series
Digital Resolution (XLP-
12 detector) 1 µW
Digital Resolution
(UP/PS thermal
detector) 1 mW
Digital Resolution (HP
detector) Autoscale
Digital Resolution
(photodetector) 10 pW
Monitor Accuracy ±1 %

5 µV
Response Time
(accelerated)
1
< 1sec
Sampling Frequency 16.7 Hz
Analog out 0-1volt (±1%)
Digital Display 77 x 58 mm LCD
LCD segments 96 (55 segments for needle)
Needle accuracy 0.9%
Display Rate 4 Hz
Dimensions 210 mm(W) x 122 mm (H) x 44 mm (D)
Weight (including
batteries) 0.47 kg
Batteries (included) 4 Alkaline AA batteries
Current consumption
(without backlight) 5mA
Backlight current 60mA (with external 9 VDC power supply only)
Battery life (with
passive thermal 500 hours
1
Varies with detector head.
