Amcor NanoMax Portable Air Conditioner - Manual (Page 3)

Specifi cations
3
Model NanoMax ™ Series
Cooling Capacity 7,000 - 12,000 BTU/h
Power Supply 115V / 60Hz
Power Consumption 680 - 830 watts
Current 6.8 - 7.9A
Dehumidification 42 - 50 Pints / 24h
Refrigerant R22
Compressor Rotary
Fan Speeds 2
Thermostat 62º - 90º F
Timer 1 - 12 Hours
Dimensions 12"W x 15"D x 30"H
Weight 50 lbs.
Subject to modifications without prior notice.
Please refer to the rating label for greater precision.
Parts
4
1. Handle
2. Control panel
3. Air outlet
4. Air inlet with filter
5. Exhaust hose with adapter
6. Power cord hanger
7. Exhaust air outlet
8. Water stopper (plug inside)
9. Casters
10. Adjustable Window Slide Bar
11. Flexible Drain Hose
12. Exhaust hose
13. IR Ergonomic Remote Control
14. Exhaust Hose Window
Slide Bar Connector
15. Insulation tape
16. Spiral water pipe with connector
5
8
7
9
6
4
1
2
3
4
11
10
12
13
16
14
15
