Atlantic Technology IWCB-727 THX - Manual (Page 2)

©2007 Atlantic Technology • 343 Vanderbilt Ave.
Norwood, MA 02062 • 781.762.6300
www.atlantictechnology.com 11.07
Atlantic Technology is a registered trademark of Atlantic Technology
International. THX and THX Select2 are trademarks of THX Inc.
Specifications subject to change without notice.
Specifications
IWCB-727
Type 2½-way M-T-M array
Drivers Woofer (2) 6 ½” (165mm) Carbon Fiber
Tweeter 1” (25mm) LRT™ soft dome
Frequency Response 75Hz – 20kHz ±3dB
Nominal Impedance 6 Ohms
Crossover Frequency 800Hz, 2.2kHz
Sensitivity 89dB
Recommended Power 10 – 140 Watts RMS
Dimensions (W x H x D) 12 5⁄16 x 21 5⁄8 x 3 7⁄8”
312 x 547 x 100mm
Cutout Dimensions (W x H x D) 11 1⁄8 x 20 3⁄8”
283 x 518mm
Net Weight 13lbs; 5.9kg each
*IR Receiver not included
Punchout for use with IR Receivers*
Boundary Compensation, High Frequency
Energy and Directivity switches
Solid MDF construction
Paintable grille and frame
Carbon fiber 6½” woofers
Installation-friendly three piece system
The systems are uniquely easy to mount, since their GFR grille/frame assemblies are sold separately. This means the
installer can run the wire to the speaker locations, then mount and paint the grille/frames to match the room. The
speaker assemblies can be installed at a later time if desired, optimizing the timing of the project.
For ease of installation
and total flexibility/
convenience, the
IWCB-727 uses the
same grill/frame
assembly and New
Construction Bracket
as the IWCB-626 (the
GFR-626 and
IN-NC-626).
IWCB-727 THX Closed-Box In-Wall
