22
-EN
3
-3 Turn the Rotary encoder to select the desired bass
center frequency, and then press / ENTER.
60 (Hz) 80 (Hz) 100 (Hz) 120 (Hz) 60 (Hz)
Emphasizes the displayed bass frequency ranges.
4
Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
• The function is inoperable when DEFEAT is set to ON.
*
2
The adjustment can also be made by pressing IMPRINT. Refer to
“Adjusting Subwoofer/Bass/Treble/Balance (Between Left and
Right)/Fader (Between Front and Rear)/Loudness/Defeat” (page 20).
Setting the Treble Control
You can change the Treble Frequency emphasis to create your own tonal
preference.
For this unit, the following setting can be made only when the
IMPRINT audio processor (PXA-H100) is not connected.
1
Press and hold AUDIO for at least 2 seconds to
activate the AUDIO selection mode.
2
Turn the Rotary encoder to select the TREBLE
Adjustment mode, and then press
/ ENTER.
SUBW SUBW SYSTEM* 1 BASS TREBLE
HPF SUBW
* 1 Displayed only when subwoofer is ON.
3
-1 *
2 Turn the Rotary encoder to select the desired
treble level (–7~+7), and then press
/ ENTER.
You can emphasize the treble level.
3
-2 Turn the Rotary encoder to select the desired
treble center frequency, and then press / ENTER.
10.0 kHz 12.5 kHz 15.0 kHz 17.5 kHz
10.0 kHz
Emphasizes the displayed treble frequency ranges.
4
Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
• The function is inoperable when DEFEAT is set to ON.
* 2 The adjustment can also be made by pressing IMPRINT. Refer to
“Adjusting Subwoofer/Bass/Treble/Balance (Between Left and
Right)/Fader (Between Front and Rear)/Loudness/Defeat” (page 20).
Adjusting the High Pass Filter
The High Pass Filter on this unit can be adjusted to suit your personal
taste.
For this unit, the following setting can be made only when the
IMPRINT audio processor (PXA-H100) is not connected.
1
Press and hold AUDIO for at least 2 seconds to
activate the AUDIO selection mode.
2
Turn the Rotary encoder to select the HPF
Adjustment mode, and then press
/ ENTER.
SUBW SUBW SYSTEM* 1 BASS TREBLE
HPF SUBW
*
1
Displayed only when subwoofer is ON.
3
Turn the Rotary encoder to select the desired HPF
frequency, and then press
/ ENTER.
OFF 60 (Hz) 80 (Hz) 100 (Hz)
4
Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
• The function is inoperable when DEFEAT is set to ON.
Setting the Bass Center Frequency
Setting the Treble Level
Setting the Treble Center Frequency
