Page 36
36
W
IRING
D
IAGRAM
Model 924505, 506
Item Part No.
Qty.
Description
1
02485000 AR
Headlamp, Oval with 1156 Bulb
2
07532900
2
Warmer, Hand - with Terminal Recommend Fast Drying Epoxy for Installation
3
AR
Battery Recommend 340 to 350 CCA at 0° F. Size U1R or U1L
4
03679000
1
Solenoid
5
02488700
1
Wire Harness 12 Volt
6
52709300
1
Switch Assembly
7
00524700
1
15 AMP Fuse
8
02485700
1
Switch, Hand Warmer
9
02485600
1
Switch, Chute Motor
10
52416500
1
Motor, Electric Right Hand- Chute
PS0850
ENGINE
B
ROWN
KEY
SWITCH
MAGNETO
RED
D.C. CHARGE
A.C. LIGHTING
RED
STARTER
BLACK
RED
RED
YELLOW
PURPLE
WHITE / BLACK
M
G
B
A
A
S
R
RE
D
1
HEAD LIGHT
BLACK
2
YELLOW
BROWN/ORANGE
YELLOW
BLACK
1
1
2
2
1
1
2
2
FUSE
15 AMP
A
B
BR
O
WN/ORANGE
1
2
4
5
3
6
BLACK
PURPLE
A
B
BLACK/VIOLET
VIOLET
CHUTE MOTOR
SWITCH
CHUTE MOTOR
BLACK
STARTER
SOLENOID
COIL 2
COIL 1
BLACK
BATTERY
HAND WARMER
SWITCH
HAND
WARMERS
LEFT
RIGHT
1
2
2
3
4
5
6
7
9
10
8
