Elite Screens CineTension2 Ceiling Kit - Manual (Page 7)

Rev. 062309‐JA
www.elitescreens.com [email protected]
ZCTE Ceiling Trim Kit Dimensions Table
Unit: mm
Models
Suspension
Bars Distance
Horizontally
(A)
Suspension
Bar Hole
Distance
(A1)
Height from
Ceiling Panel to
Suspension Bar
(B)
Suspension
Bar Height
(B1)
Suspension
Bar Hole
Distance
(B2)
Distance Between
Suspension Bars
Vertically (C)
ZCTE84V 2103 2079 960 900 50 177
ZCTE100V 2507 2483 960 900 50 177
ZCTE120V 2949 2925 960 900 50 177
ZCTE135V 3254 3230 960 900 50 177
ZCTE84H 2256 2232 960 900 50 177
ZCTE92H 2507 2483 960 900 50 177
ZCTE100H 2684 2660 960 900 50 177
ZCTE106H 2837 2813 960 900 50 177
ZCTE120H 3176 3152 960 900 50 177
ZCTE135H 3508 3484 960 900 50 177
Unit: Inches
Models
Suspension
Bars Distance
Horizontally
(A)
Suspension
Bar Hole
Distance
(A1)
Height from
Ceiling Panel to
Suspension Bar
(B)
Suspension
Bar Height
(B1)
Suspension
Bar Hole
Distance
(B2)
Distance Between
Suspension Bars
Vertically (C)
ZCTE84V 82.8 81.9 37.8 35.4 2.0 7.0
ZCTE100V 98.7 97.8 37.8 35.4 2.0 7.0
ZCTE120V 116.1 115.2 37.8 35.4 2.0 7.0
ZCTE135V 128.1 127.2 37.8 35.4 2.0 7.0
ZCTE84H 88.8 87.9 37.8 35.4 2.0 7.0
ZCTE92H 98.7 97.8 37.8 35.4 2.0 7.0
ZCTE100H 105.7 104.7 37.8 35.4 2.0 7.0
ZCTE106H 111.7 110.7 37.8 35.4 2.0 7.0
ZCTE120H 125.0 124.1 37.8 35.4 2.0 7.0
ZCTE135H 138.1 137.2 37.8 35.4 2.0 7.0
