Elite Screens ZA56-WP - Manual (Page 2)

Rev.080811-AS
www.elitescreens.com
Parts List for ZA56
Please make sure all parts listed below are included before proceeding with the installation.
A.
D.
A. M10x40mm Wall Anchor
B. M5x50mm Wall screw
C. M5 Washer
D. ZA56-WP Wall Plates
E. M6x20mm Screw/Washer/Bolt
[email protected]
Parts List for ZA56-WP Wall Plates
make sure all parts listed below are included before proceeding with the installation.
B.
E.
Parts Qty
M10x40mm Wall Anchor 8
B. M5x50mm Wall screw 8
8
Wall Plates 2
6x20mm Screw/Washer/Bolt 4
2
1
make sure all parts listed below are included before proceeding with the installation.
C.
