Surface Recessed
Men
Women
Children
ages 3-7
Children
ages 8-10
Children
ages 11-13
Children
ages 14-17
Disabled
46" (117cm)
44" (112cm)
32" (81cm)
40" (102cm)
36" (91cm)
44" (116cm)
37" (94cm)
42" (107cm)
40" (102cm)
28" (71cm)
36" (91cm)
32" 81cm)
40" (102cm)
34" (86cm)
Measured from floor to the bottom of the unit
MOUNTING HEIGHTS
ELECTRICAL
SPECIFICATIONS
11.6"
(295 mm)
SURFACE MOUNTED
10.9"
(277 mm)
5.5 "
(140 mm)
RECESS
MOUNTED
PLANNING GUIDE
RECESS KITS
In order to recess dryers, specify a
recess kit in addition to the dryer.
Includes steel mounting box with
chrome trim.
Specify Kit: KNTR-973
QUANTITY ESTIMATE
Average traffic:
1 dryer per 2 washbasins
Heavy traffic:
1 dryer per washbasin
54” Bradley sink:
4 dryers per sink
INSTALLATION
Hand dryers require a dedicated
20 AMP circuit, and must be
properly grounded. GFI circuit
protection is recommended. One
side of dryer should be mounted
to a stud.
DRYER PLACEMENT
Hand dryers should be placed at
least 2 feet apart, near but not
over the washbasin. In congested
areas dryers should be placed to
create a traffic flow from wash
basin to dryer to exit. Automatic
dryers should be placed more
than 18” above or away from
projections, which may interfere
with the operation of the
automatic sensor.
* Export Models only
M
O
D
EL
N
U
M
B
ER
EL
EC
TR
IC
A
L
W
A246
W
A126-2
W
A235*
W
A126
V
ol
ts
208/240
120 230 120
A
m
ps
8.
5
13 8 17
W
atts
2000 1500 1800 2000
Freq
60 Hz 60 Hz 50 Hz 60 Hz
Airspeed
Push button
NT246
---
NT235* NT126
No
Touc
h
A
utomatic
MEASUREMENTS
MOUNTING
STYLE
Surface
with Optional
Recessed Kit
UNIT
MEASUREMENTS
13" L x 12" W x 9-1/2" H
16" L x 15" W x 14" H
22 lbs
31 lbs
SHIPPING
WEIGHT
10-29/32" W x 11-5/8" H x 7-1/2" D
12-3/4" W x 13-1/2" H x 5-1/2" D
SHIPPING
DIMENSIONS
COVER OPTIONS
MODEL
Airspeed™
No Touch™
White
001
004
Chrome
002
005
MODEL NT™
Chrome Housing MODEL WA™
White Housing
Drawings not to scale
RECESS
MOUNTED
SIDE VIEW
1.25"
(32 mm)
.8" (22 mm) / 1.1" (28 mm)
8 locations
Electrical Knockouts
.2" (5 mm) diameter
8 locations
(89 mm) 3.5"
1.25"
(32 mm)
11.75"
12"
(318 mm)
(298 mm)
WALL BOX
ORDERING INFORMATION
When specifying and/or ordering hand dryer include the model number
with the cover option. (ie. WA126-002)
